CKC Lighting

EV Block IP

SKU: CKC- EV Block IP

Source: 800 x 0.5W RGB LED
Source: 48 x 5W CW LED
Output：12000 Lm
Beam angle：RGB：X：66° Y：65°
Beam angle：CW：X：78° Y：42°
Field angle：RGB：X：123° Y：110°
Field angle：CW：X：120° Y：79°
CCT：2300K~9000 K
IP rating：IP65
Size：417 × 154 × 262 mm
N.W：8.9 kgs

Pay in 4 interest-free installments of $133.12 with

Key Features

Source：800 x 0.5W RGB LED
48 x 5W CW LED
Output：12000W
Rated power：205 W
Strobe power：600 W
Resistant to salt corrosion
Specifications

OPTIC
Source：800 x 0.5W RGB LED
Source：48 x 5W CW LED
Output：12000 Lm
Beam angle：RGB：X：66° Y：65°
Beam angle：CW：X：78° Y：42°
Field angle：RGB：X：123° Y：110°
Field angle：CW：X：120° Y：79°
CCT：2300K~9000 K
Source lifetime：>20000 H
EFFECT
Strobe：1～25Hz
LED refresh rate：900Hz~25KHz
Dimming Mode：6
Dimming Curve：4
CONTROL & PROGRAM
Channel：14 / 32 / 37 / 47 / 77 / 126 / 137 CH
Protocal：DMX512, RDM
Data connector: 3 PIN (or 5 PIN) XLR
Display：OLED display
SOFTWARE
Via DMX signal to update
Static waterproof fan, intelligent speed control
Intelligent temperature protection to ensure LED service life
HOUSING
Aluminum alloy structure
Fan cooling
Resistant to salt corrosion
OTHER
IP rating：IP65
Work environment：-40℃—45℃
Startup environment：-20℃—45℃
POWER CONSUMPTION
Voltage：AC 100V-240V 50/60HZ
Rated power：205 W
Strobe power：600 W
SIZE & WEIGHT
Size：417 × 154 × 262 mm
N.W：8.9 kgs
Carton Size：530 × 530 × 380 mm
G.W：22.5 kgs (2PCS)
Included Accessories
Downloads
EV Block IP Data Sheet
Buying Guide

Is the EV Block IP right for you?

The EV Block IP pairs an RGB source of 800 x 0.5W LEDs with a 48 x 5W CW source, giving 12000 Lm and a CCT range of 2300K to 9000K. It is IP65 rated and resistant to salt corrosion, with a working range of -40°C to 45°C, so it suits rental houses and production companies running strobes in exposed conditions. Control is by DMX512 and RDM, with channel modes from 14 CH to 137 CH. It weighs 8.9 kg.

Also in the range

Related CKC Lighting items include EV Block, EV Stick IP and EV Stick. See all strobes.

Need help choosing? Call StageKraft on +61 2 9982 1494 or email sales@stagekraft.com.au.
