Creos

18 x 40W RGBL Osram LEDs
Individual pixel control
5°–60° motorised zoom
IP65-rated housing
5-pin DMX and RDM
Art-Net support
iQ.Mesh compatibility
26 kg body
Includes bracket 87077

LIGHT SOURCE
Type RGBL LED
Power per pixel: 40 W | total: 720 W
Count 18
Lifetime 20.000 h
CRI 85+
TLCI 75+
TM-30-15 Rf/Rg 104 / 80
LED Refresh Rate Low | Optimal | High 1 | High 2
OPTICAL SYSTEM
Output 10,800 lm
Peak Luminous
Intensity 1.24 Mcd
Min. Zoom 4°
Max. Zoom 50°
Zoom Ratio 1:13
DYNAMIC EFFECTS
Color Mixing RGB | RGBL | x;y
Color Wheel virtual, 64 LEE referenced
colors, rainbow
Dimmer / Shutter 16 bit
Dimmer curves Linear | Square | S-curve
CTC 2,500 – 10,000 K
CQC High Output (HO) | High Quality
(HQ) | Desaturation
Magenta/Green-Shift yes
Tungsten Simulation 8x linked to fix CCT
8x relative to Colormix
Pattern Effects >50 static Pattern + 50 dynamic
Pattern with index and
rotation; random Pixel; pattern
crossfade effects; Pattern
Transition effects
Color Mix Priority Layer Priority Channel
MOVEMENT
Tilt 190°, 16 bit
CONTROL & PROGRAMMING
DMX Channels 22 | 34 | 42 | 51 | 87 | 66 | 84
Control Modes 7
High-Res Channels Dimmer | Tilt
Dimming curves Linear | Soft | etc.
Performance Modes Fast | Normal | Smooth
Fan Modes Regulated | High | Medium |
Max
Protocols DMX (USITT DMX512-A) |
RDM (ANSI/ESTA E1.20) |
Art-Net | GLP iQ.Mesh |
LumenRadio CRMX
Setting and
addressing
Control panel with backlit
graphic display | 4 Button
Menu Navigation | DMX |
RDM | 1 Scene Stand Alone
Others 2 Layer Pattern-FX-Engine
| 50 static und 50 dynamic
patterns | GLP FX.Port for
external electro-mechanical
Acessories
Software Update DMX Link via DProg |
GLP iQ.Mesh via Service App |
GLP iQ.Tool
CONNECTIONS
Power connection powerCON True1 In/Out
Signal connection XLR 5-Pin In/Out | etherCon
In/Out Port A&B (failsafe) |
GLP FX.Port at Fixture Head
ELECTRICAL SPECIFICATIONS
Power input 100 – 240 V AC / 50 – 60 Hz
Power supply unit auto-ranging electronic
switch-mode
Max. Power 800 W
THERMAL SPECIFICATIONS
Cooling type combined convection and
forced air
Thermal Protection automatic
Max. ambient
temperature 45 °C / 113 °F
Min. ambient
temperature -10 °C / 14 °F
Total heat
dissipation 2,750 BTU/h
INSTALLATION
Mounting 2 pairs of 1/4-turn locks |
2x Safety Cable attachment
point | option for direct clamp
installation
Orientation Any
Location Outdoor | Indoor
CONSTRUCTION
Housing color Black
Material Aluminum
Protection Rating IP 65
Construction
Features
Tilt-Lock-System |
integrated base handles
SHIPPING
Tourpack 4-way
DIMENSIONS & WEIGHT
Height 375 mm / 14.76 in
Width 388 mm / 15.27 in
Depth 218 mm / 8.58 in
Weight netto 20.3 kg / 44.75 lbs
ARTICLE NUMBERS
Creos 7558

1 x bracket (87077)
