Technical Data (1/2) LIGHT SOURCE Type RGBL LED Power per pixel: 40 W Count 16 Lifetime 50,000 h LED Refresh Rate 4 selectable PWM Modes OPTICAL SYSTEM Output up to 10,300 lm Min. Zoom 4° Max. Zoom 44° Zoom Ratio 1:12 DYNAMIC EFFECTS Color mixing RGBL Dimmer 0 – 100 %, 16 bit MOVEMENT Tilt 200°, 16 bit Technical Data (2/2) CONTROL & PROGRAMMING DMX Channels 28 | 79 Control Modes Basic | Pixel Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | Art-Net | sACN | GLP iQ.Mesh High-Res Channels Pan | Tilt Dimming Curves Linear | Soft | S-Curve Performance Modes Fast | Normal (Balanced) | Smooth Fan Modes Regulated | High | Medium | Low PWM Low | Optimal | High 1 | High 2 Setting and addressing Backlit graphic LCD | 4 Button Menu | DMX | RDM Others 1 Scene Stand Alone | PatternFX-Engine Firmware Update GLP iQ.Mesh CONNECTIONS Power connection Neutrik PowerCon True1 In/ Out Signal connection Neutrik XLR 5-Pin In/Out | Neutrik etherCON port (failsafe) ELECTRICAL SPECIFICATIONS Power input 100 – 240 V AC / 50 – 60 Hz Power supply unit Auto-ranging electronic switch mode Max. Power 700 W THERMAL SPECIFICATIONS Cooling Type combined convection and forced air Temperature range, Operating-10 °C – 45 °C / 14 °F – 113 °F Thermal Protection automatic INSTALLATION Mounting 4 pairs of 1/4-turn locks for two rigging/installation brackets | Safety cable attachment point Orientation Any Min. distance to combustible materials 1 m Min. distance to illuminated surfaces 0.1 m Location Indoor | Outdoor CONSTRUCTION Housing color Black Material High-impact flame-resistant thermoplastic | Aluminum | Steel Protection Rating IP 65 Construction Features Tilt-Lock-System | Alignment System | optional: Frontfilter Adapter SHIPPING Single fixture cartboard; Sleeve (incl.) Tourpack 3-way DIMENSIONS & WEIGHT Height without rubber feet with rubber feet 306 mm / 12 in 321 mm / 13 in Width across yoke 1,000 mm / 40 in Depth 112.7 mm / 4.5 in Weight netto 23 kg / 50.5 lbs ARTICLE NUMBERS WildBar 16 7453 DRX Sleeve (1/2) 2 required for 1 WildBar 16 56802
