CKC Lighting

FC Profile 500IP

SKU: CKC-FCProf500IP

Source: 500W RGBAL LED
Output：18900 Lm
Zoom Range：14° /19° /26° /36° /50° /70°
(Universal Profile 300 Full Series Lens Assembly）
CRI: 93
CCT：2400K ~ 8500K
Full color light source creates infinite dynamism and infinite color changes
IP66 / Resistant to salt corrosion
Size：314 × 689 × 480 mm
N.W：10 kgs

Pay in 4 interest-free installments of $133.12 with

Key Features

Source: 500W RGBAL LED
Output：18900 Lm
Zoom Range：14° /19° /26° /36° /50° /70°
（Universal Profile 300 Full Series Lens Assembly）
CRI: 93
CCT：2400K ~ 8500K
Full color light source creates infinite dynamism and infinite color changes
IP66 / Resistant to salt corrosion
Specifications

OPTIC
Source: 500W RGBAL LED
Output：18900 Lm
CRI：93
Outdoor lens
Zoom Range：14° /19° /26° /36° /50° /70°
（Universal Profile 300 Full Series Lens Assembly）
CCT：2400K ~ 8500K
Source lifetime：>20000 H
EFFECT
Strobe：1~25Hz
Gobo：1
Gobo: Ф30mm, lmage: Ф25 mm, thickness: 1.1mm
Framing：Manual
CONTROL & PROGRAM
Channel：1 / 4 / 6 / 9 / 10 / 11 / 13 / 15 / 19 CH
Protocal：DMX512, RDM
Data connector：3 PIN (or 5 PIN) XLR
Display：OLED display
SOFTWARE
Via USB & DMX signal to update
Silent fan, intelligent speed regulation
Intelligent temperature protection to ensure LED service life
HOUSING
Structure of metal injection molded parts
Fan cooling (intelligent speed regulation)
Resistant to salt corrosion
OTHER
IP rating：IP66
Work environment：-40℃—45℃
Startup environment：-20℃—45℃
POWER CONSUMPTION
Voltage：AC 100V-240V 50/60HZ
Rated power：485W
SIZE & WEIGHT
Size：314 × 689 × 480 mm
N.W：10 kgs
Included Accessories
Downloads
FC Profile 500IP Data Sheet FC Profile 500IP User Manual FC Profile 500IP DWG
Buying Guide

Is the FC Profile 500IP right for you?

The FC Profile 500IP is a 500W RGBAL LED profile from the CKC Lighting Ellipsols series, built for rigs that sit outdoors. The IP66 rating, salt corrosion resistance and a working range of -40℃ to 45℃ suit exposed positions. Output is 18900 lm at CRI 93, with CCT from 2400K to 8500K and a zoom range of 14° to 70°. Control is DMX512 and RDM, and the fan is silent with intelligent speed regulation.

Also in the range

Related CKC Lighting profiles include FC Profile 300, FC Profile 400 and Profile 300WW. See all profile.

Need help choosing? Call StageKraft on +61 2 9982 1494 or email sales@stagekraft.com.au.
