CKC Lighting

Profile 300WW

SKU: CKC-Prof 300

Source: 300W WW LED
Zoom Range：5°/10°/14°/19°/26°/36°/50°/15 ~ 30°/25 ~ 50°(Optional)
CCT: 3200K/4500K/5600K(Optional)
CRI: 95
Output：9000 Lm
Framing：Manual
IP rating：IP30
Size：683 × 302 × 456 mm
N.W：9.1 kgs

Pay in 4 interest-free installments of $133.12 with

Key Features

Zoom Range：5°/10°/14°/19°/26°/36°/50°/15 ~ 30°/25 ~ 50°(Optional)
CCT：3200K/4500K/5600K(Optional)
CRI：95
Output：9000 Lm
Framing：Manual
Specifications

OPTIC
Source：300W WW LED
Zoom Range：5°/10°/14°/19°/26°/36°/50°/15 ~ 30°/25 ~ 50°(Optional)
CCT: 3200K/4500K/5600K(Optional)
CRI: 95
Output：9000 Lm
Source lifetime：>20000 H
SUITABLE FOR THE VENUE
TV station studio, professional stage, interview with reporters, shooting film and television lights, conference halls, etc.
EFFECT
Strobe：1 ~ 25Hz
Framing：Manual
DimCurve：4 kinds
CONTROL & PROGRAM
Channel：1 / 3 / 4 CH
Protocal：DMX512, RDM
Data connector：3 PIN (or 5 PIN) XLR
Display：OLED display
SOFTWARE
Via DMX signal to update
Silent fan, intelligent speed regulation
Intelligent temperature protection to ensure LED service life
HOUSING
Structure of metal injection molded parts
Fan cooling
OTHER
IP rating：IP30
Work environment：-40℃—45℃
Startup environment：-20℃—45℃
POWER CONSUMPTION
Voltage：AC 100V ~ 240V 50/60Hz
Rated power：262 W
SIZE & WEIGHT
Size：683 × 302 × 456 mm
N.W：9.1 kgs
Carton Size：740 × 375 × 365 mm
G.W：15 kgs
Included Accessories
Downloads
Profile 300WW Data Sheet
Buying Guide

Is the Profile 300WW right for you?

The Profile 300WW is a 300W WW LED profile from the CKC Lighting Ellipsols series. It suits TV studios, professional stages, conference halls, interviews and film and television shooting. With CRI 95 and 9000 lm output, it covers a 5° to 50° zoom range with manual framing. A silent fan with intelligent speed regulation suits quiet rooms, and DMX512 and RDM control make it straightforward to patch. It weighs 9.1 kg.

Also in the range

For other CKC Lighting profiles, see FC Profile 300, FC Profile 400 and Mini Profile 50WW. See all profile.

Need help choosing? Call StageKraft on +61 2 9982 1494 or email sales@stagekraft.com.au.
