Technical Data (1/2) LIGHT SOURCE Type Count Power Lifetime RGBAL LED 4 Heads each Head: max. 350 W 50,000 h OPTICAL SYSTEM Output BOOST RGBAL CONST RGBAL up to 45,200 lm up to 26,200 lm Beam angle 60° Beam angle 100° Field angle DYNAMIC EFFECTS Dimmer Shutter Control CTC 8 bit | 16 bit Duration Control | Rate Control | IntensityFX Control Open | 2,500 K – 10,000 K Tungsten Simulation 8x linked to fix CCT | 8x relative to Colormix Output Modes Boost: 350 W | Constant: 175 W CONTROL & PROGRAMMING DMX Channels 4 | 19 | 76 | 12 Control Modes 4 Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | iQ.Mesh High-Res Channels Dimmer Dimming Curves Linear | Square | S-Curve Color Mix Mode RGB | RGBAL Color Mix Speed Snap | Fade Fan Modes Regulated | High | Medium | Low Pixel Mirror x-mirror | y-mirror | xy-mirror | Off Pixel Rotation 90° | 180° | 270° | Off PWM Frequency Optimal | High 1 | High 2 | Max White Points 8,000 K | 6,500 K | 5,600 K | 4,200 K | 3,200 K | Off Duration Control Normal | Percentage Output Modes Boost | Constant Hibernation yes Setting and addressing Control panel with backlit graphic display | 4 Button Menu Navigation | DMX | RDM | iQ.Mesh | Stand Alone Scene Firmware Update DMX Link via DProg | iQ.Mesh via Service App | iQ.Tool CONNECTIONS Power connection Seetronic powerCON TRUE1 In/Out Signal connection Seetronic XLR 5-Pin In/Out ELECTRICAL SPECIFICATIONS Power input 100 – 240 V AC / 50 – 60 Hz Power supply unit Auto-ranging electronic switch-mode Max. Power 1,400 W THERMAL SPECIFICATIONS Cooling Type active fan cooling Temperature range-10 °C / 14 °F to 45 °C / 113 °F Thermal Protection Automatic Total heat dissipation 4,800 BTU/h INSTALLATION Mounting 4x pair of 1/4-turn locks (Frame Top, Frame side, Back side, yoke) | 2x Safety Cable attachment point (back bone) Orientation Any | horizontal sideway | vertical hanging Location Indoor | Outdoor CONSTRUCTION Housing Color Black Housing Material High-impact flameresistant thermo-plastic | Aluminum | Steel Metal Plates Protection Rating IP 65 Construction Features Alignment & Linking System | +/-20° individual Head-PanAngle DIMENSIONS & WEIGHT Height 400 mm / 15.8 in Width 400 mm / 15.8 in Depth without yoke with yoke 246 mm / 9.7 in 353 mm / 13.9 in Weight Fixture only with Yoke 400/200 13.5 kg / 29.8 lbs 15.3 kg / 33.7 lbs WEIGHT YOKES Yoke 400/200 1.8 kg / 4 lbs SHIPPING Tourpack Flightcase, 4-way; DRX Sleeve (incl.) ARTICLE NUMBERS Matrix Eye 4 7458 Yoke 400/200 (incl.) 32001 DRX Sleeve for Eye 4 (incl.) 56804
