Technical Data (1/2) LIGHT SOURCE Type White Light LED Engine High CR Spectrum Power 500 W Count 1 Lifetime 20,000 h Total Output 26,000 lm CCT 6,000 K CRI 95+ TLCI 95+ TM-30-15 Rf/Rg 100 / 92 OPTICAL SYSTEM Output up to 13,100 lm Min. Zoom 7° Max. Zoom 65° Zoom ratio 1:6 Output Lens Diameter 185 mm / 7.3 in Technical Data (2/2) DYNAMIC EFFECTS Color mixing CMY, 8 bit, 0 – 100 % Color wheel 10 colors + open | 7 fix colors | 4 spectral filters CTC 2,500 – 8,000 K using CMY System Zoom Resolution 8 bit Focus 16 bit, with focus tracking option Dimmer / Shutter 100 % electronic, 16 bit Framing 4 separately movable shutters, +/-30° positionable, 100% positionable into the beam | +/- 45° rotatable module MOVEMENT Pan 540°, 16 bit | extended 565° Tilt 256°, 16 bit CONTROL & PROGRAMMING Control Modes 27 DMX Channels 1 Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | Art-Net | sACN | GLP iQ.Mesh | FVP Port High-Res Channels Dimmer | Tilt | Pan Dimming Curves Linear | Soft | S-Curve Performance Modes Fast | Normal (Balanced) | Smooth Fan Modes Regulated | High | Medium | Low | Minimum No signal Blackout | Hold | Scene PWM Optimal | High 1 | High 2 | Max Setting and addressing backlit graphic LCD | 4 Button Menu Navigation | DMX | RDM | Stand Alone Scene | iQ.Mesh Software Update DMX Link via Dprog | GLP iQ.Mesh via Service App | GLP iQ.Tool CONNECTIONS Power connection Neutrik powerCON TRUE1 In/ Out Signal connection Neutrik XLR 5-Pin In/Out | 2x Neutrik etherCON port (failsafe) ELECTRICAL SPECIFICATIONS Power input 100 – 240 V AC / 50 – 60 Hz Power supply unit Auto-ranging electronic switch-mode Max. Power 750 W THERMAL SPECIFICATIONS Temperature Range, operating 5 °C – 45 °C / 40 °F – 115 °F Thermal Protection Automatic overtemperature protection Total heat dissipation 2,100 BTU/hr INSTALLATION Mounting 4 pair of 1/4-turn locks | 2x Safety Cable attachment point Orientation Any | horizontal sideway | vertical hanging Location dry location only CONSTRUCTION Housing material High-impact flame-resistant thermoplastic | Aluminum | Steel Protection Rating IP20 Construction Features baseless design | Tilt-Lock- System | Multicolor display SHIPPING Single fixture Cartboard DIMENSIONS & WEIGHT Height Head vertical 652 mm / 25.6 in Width 472 mm / 18.5 in Depth 230 mm / 9 in Weight netto 26.6 kg / 58.6 lbs ARTICLE NUMBERS S500 Wash HC 7960 No responsibility taken for misprints, errors, and technical changes. Technical drawings and product depictions are representative only and can vary from the original items. Technical data is subject to change without notice as a result of product modification. © GLP GLP German Light Products GmbH | Industriestr. 2 | 76307 Karlsbad | Germany | Register court: Mannheim | Trade register (HRB): 361719 | CEO: Udo Künzler | Telephone: +49 (0)72 48 / 927 19 – 0 | Fax: +49 (0)72 48 / 927 19 – 30 | E-Mail: info@glp.de | Web: www.glp.de 05/2025Technical Data (2/2) DYNAMIC EFFECTS Color mixing CMY, 8 bit, 0 – 100 % Color wheel 10 colors + open | 7 fix colors | 4 spectral filters CTC 2,500 – 8,000 K using CMY System Zoom Resolution 8 bit Focus 16 bit, with focus tracking option Dimmer / Shutter 100 % electronic, 16 bit Framing 4 separately movable shutters, +/-30° positionable, 100% positionable into the beam | +/- 45° rotatable module MOVEMENT Pan 540°, 16 bit | extended 565° Tilt 256°, 16 bit CONTROL & PROGRAMMING Control Modes 27 DMX Channels 1 Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | Art-Net | sACN | GLP iQ.Mesh | FVP Port High-Res Channels Dimmer | Tilt | Pan Dimming Curves Linear | Soft | S-Curve Performance Modes Fast | Normal (Balanced) | Smooth Fan Modes Regulated | High | Medium | Low | Minimum No signal Blackout | Hold | Scene PWM Optimal | High 1 | High 2 | Max Setting and addressing backlit graphic LCD | 4 Button Menu Navigation | DMX | RDM | Stand Alone Scene | iQ.Mesh Software Update DMX Link via Dprog | GLP iQ.Mesh via Service App | GLP iQ.Tool CONNECTIONS Power connection Neutrik powerCON TRUE1 In/ Out Signal connection Neutrik XLR 5-Pin In/Out | 2x Neutrik etherCON port (failsafe) ELECTRICAL SPECIFICATIONS Power input 100 – 240 V AC / 50 – 60 Hz Power supply unit Auto-ranging electronic switch-mode Max. Power 750 W THERMAL SPECIFICATIONS Temperature Range, operating 5 °C – 45 °C / 40 °F – 115 °F Thermal Protection Automatic overtemperature protection Total heat dissipation 2,100 BTU/hr INSTALLATION Mounting 4 pair of 1/4-turn locks | 2x Safety Cable attachment point Orientation Any | horizontal sideway | vertical hanging Location dry location only CONSTRUCTION Housing material High-impact flame-resistant thermoplastic | Aluminum | Steel Protection Rating IP20 Construction Features baseless design | Tilt-Lock- System | Multicolor display SHIPPING Single fixture Cartboard DIMENSIONS & WEIGHT Height Head vertical 652 mm / 25.6 in Width 472 mm / 18.5 in Depth 230 mm / 9 in Weight netto 26.6 kg / 58.6 lbs ARTICLE NUMBERS S500 Wash HC 7960
