HIGH-OUTPUT LIGHT QUALITY FEATURE PACKAGE Key Facts {HC Version: 10,700 lm {HO Version: 14,800 lm {CRI 90+ {40° to 7.5° Zoom range {540° or 565° extended Pan The new GLP impression S500 Series lifts the well-known 350W movinghead impression S350 to 500W LED power and 30% to 65% more output. In addition, the optics, software and all connections and controls have been updated to the latest technology. Compact construction, the identical S350 size factor and GLP’s baseless design allow for an easy fixture integration. The impression S500 Profile comes in two versions (Profile HC and Profile HO) and targets specific needs of different markets. The S500 Profile HC Version houses a white LED Engine with 26,000 lm at native 6,000 K and generates a very balanced light spectrum for great color rendering of CRI and TLCI above 90. Its great light quality guarantees natural and realistic skin colors and a total lumen output of 10,700 lm. The Profile HO Version houses a white LED Engine with 40,000 lm at native 7,000 K. This highly efficient light source generates more output for powerful projections and mid-air effects with a total lumen output of 14,800 lm. Both versions share a very homogenous field illumination in the range of 7.5° to 40° field angle. The vast feature package houses a CMY color mixing system, an innovative CTC color control system, a color wheel with 6 full colors and 4 color correction filters, a gobo wheel with 7 rotating gobos plus open, a second gobo wheel with 10 static gobos plus open, a 90° adjustable animation wheel, a fadeable frost system from soft to medium, a precise 4-blade framing system with blade tilt and framing rotation, a rotating 8-facet prism and motorized 540°/565° pan and 256° tilt movement. Technical Data (1/2) LIGHT SOURCE Type S500 Profile HC S500 Profile HO White Light LED Engine High CR Spectrum High Output Spectrum Power 500 W Count 1 Lifetime 20,000 h CCT S500 Profile HC S500 Profile HO 6,000 K 7,000 K CRI S500 Profile HC S500 Profile HO 90+ 70 TLCI S500 Profile HC 90+ OPTICAL SYSTEM Output S500 Profile HC S500 Profile HO up to 10,700 lm up to 14,800 lm Min. Zoom 7.5° Max. Zoom 40° Zoom ratio 1:6 Output Lens Diameter 140 mm Technical Data (2/2) DYNAMIC EFFECTS Color mixing CMY, 8 bit, 0 – 100 % Color wheel 10 colors + open | 7 fix colors | 4 spectral filters CTC 2,500 – 8,000 K using CMY System Zoom Resolution 8 bit Focus 16 bit, with focus tracking option Dimmer / Shutter 100 % electronic, 16 bit Animation wheel Rotating Wave Pattern Frost 2-way (soft, medium) Prism 8-way, rotating Gobo wheel 7 Gobos, rotating + open Gobo wheel 2 10 Gobos, fixed + open Framing 4 separately movable shutters, +/-30° positionable, 100% positionable into the beam | +/- 45° rotatable module MOVEMENT Pan 540°, 16 bit | extended 565° Tilt 256°, 16 bit CONTROL & PROGRAMMING Control Modes 1 DMX Channels 35 Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | Art-Net | sACN | LumenRadio CRMX High-Res Channels Dimmer | Tilt | Pan | Focus Dimming Curves Linear | Soft | S-Curve Performance Modes Fast | Normal (Balanced) | Smooth Fan Modes Regulated | High | Medium | Low No signal Blackout | Hold | Scene PWM Optimal | High 1 | High 2 | Max Setting and addressing backlit graphic LCD | 4 Button Menu Navigation | DMX | RDM CONNECTIONS Power connection Neutrik powerCON TRUE1 In Signal connection Neutrik XLR 5-Pin In/Out | 2x Neutrik etherCON port (failsafe) ELECTRICAL SPECIFICATIONS Power supply unit Auto-ranging electronic switch mode Max. Power 750 W THERMAL SPECIFICATIONS Max. ambient temperature 5 °C – 41 °C / 45 °F – 115 °F Thermal Protection Overheating protection Total heat dissipation 2,600 BTU/hr INSTALLATION Orientation Any Location dry location only CONSTRUCTION Housing material High-impact flame-resistant thermoplastic | Aluminum | Steel Protection Rating IP20 Construction Features baseless design | Tilt-Lock- System | Multicolor display SHIPPING Single fixture Cartboard Tourpack 2-way | Flightcase inclusive Omega Brackets with handle DIMENSIONS & WEIGHT Height without tripod with tripod 651 mm / 25.6 in 676 mm / 26.6 in Width 472 mm / 18.5 in Depth 230 mm / 9 in Weight netto 26.9 kg / 57.4 lbs ARTICLE NUMBERS S500 Profile HC 7950 S500 Profile HO 7955
