X5 Dot

• RGBL LED
• 16°–68° zoom
• iQ.Gamut

Technical Data (1/2)* Preliminary Data LIGHT SOURCE Type RGBL LED Power 10 – 20 W Count 1 OPTICAL SYSTEM Output up to 550 lm Max. Peak Luminous Intensity 4.58 kcd Min. Zoom 16° Max. Zoom 68° Zoom Ratio 1:5 Light aperature diameter 50 mm / 1.96 in DYNAMIC EFFECTS Dimmer 16 bit CONTROL & PROGRAMMING DMX Channels tbd Control Modes tbd Protocols DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | GLP iQ.Mesh High-Res Channels Dimmer Setting and addressing DMX | RDM | GLP iQ.Mesh Firmware Update DMX Link via DProg | GLP iQ.Mesh | GLP iQ.Tool CONNECTIONS Power & Signal connection Combined Power/Date Cable Tail, 750 mm; with XLR 4-Pin connector mail ELECTRICAL SPECIFICATIONS Power input 24 – 48 V DC Power supply unit external, not included THERMAL SPECIFICATIONS Cooling Type convection min. ambient temperature-10 °C / 14 °F max. ambient temperature 45 °C / 113 °F Thermal Protection automatic Total heat dissipation 70 BTU/h INSTALLATION Mounting 2x 3/8" and 1/4" 20 UNC thread| combined hanging / floorstand yoke Orientation Any | horizontal sideway | vertical hanging Location Indoor | Outdoor CONSTRUCTION Housing color Black | optional: White Material High-impact flame-resistant thermoplastic | Aluminum Protection Rating IP65 DIMENSIONS & WEIGHT Weight netto 580 g / 1.28 lbs ARTICLE NUMBERS X5 Dot 7725

• 750 mm Power/Data Cable
